Analog Master Pressure Gauge

Analog Master Pressure Gauge
Analog Master Pressure Gauge
Send Inquiry
Product Code : na
Product Description

Analog Master Pressure Gauge

  • Nominal Size (mm)- 150,200,250
  • Scale Range-0.. Vacuum to 0.6 to 0..1400 kg/cm2
  • Accuracy in FSD-0.25%
  • Thread Connection-3/8", ½ ", BSP & NPT, M-20
  • Mounting of Gauge- Direct Bottom
  • Case and Bezel- SS 304/Die cast Aluminum
  • Pressure Elements- Bourdon Tube
  • Diaphragm- Nil
  • Wetted Parts- SS 316
  • Application- Testing & calibration
  • Features- Mirrored Scale Dial & Knife edge pointer

Specification

Scale Range

0 Vacuum to 0.6 to 0-1400 kg/cm2

Wetted Parts

SS 316

Application

Testing & calibration

Nominal Size

150,200,250 mm

Accuracy In FSD

0.25%

Thread Connection

3/8", 1/2 ", BSP & NPT, M-20

Mounting of Gauge

Direct Bottom

Case and Bezel

SS 304/Die cast Aluminum

Pressure Elements

Bourdon Tube

Diaphragm

Nil

Features

Mirrored Scale Dial & Knife edge pointer
