Product Description
Features: Low Angular Dependence Easy Installation Adjustable to Application requirements Range: 0 to 10 /15 /20m/s Output : 0 to 10V / 4 to 20mA Temp.Range: 0 to 50deg C Specification Measured Air Velocity Up to 20 m/s Outputs 0-1/5/10 V (max. 1 mA) Supply 24V AC/DC+- 20% Working Range Humidity 5-95 % RH (non-condensing) Protection Class IP65 Housing Material Polycarbonate, Cable Gland M16x1.5 Electrical Connection Max. 1.5 mm 2 Current Consumption max AC 180 mA rms (with Display), 74 mA rms (without Display), max DC 85 mA (with Display), 41mA
FAQs of Air Velocity Transmitters( Series EE650 ):
Q: What type of signal does the Series EE650 Air Velocity Transmitter provide?
A: The Series EE650 Air Velocity Transmitter provides an analog signal output.
Q: What is the measurement range of air velocity for the Series EE650?
A: The measurement range of air velocity is 0 to 20 meters per second (m/s).
Q: What is the accuracy of the Series EE650 Air Velocity Transmitter?
A: The accuracy of the Series EE650 Air Velocity Transmitter is 1%.
Q: What are the dimensions of the Series EE650 Air Velocity Transmitter?
A: The dimensions are 400 mm in length, 50 mm in width, and 100 mm in height.
Q: What is the power supply requirement for the Series EE650 Air Velocity Transmitter?
A: The Series EE650 Air Velocity Transmitter requires a power supply of 24 V DC.
Q: What type of sensor is used in the Series EE650 Air Velocity Transmitter?
A: The Series EE650 Air Velocity Transmitter uses a thermal anemometer sensor.
Q: What is the warranty period for the Series EE650 Air Velocity Transmitter?
A: The warranty period for the Series EE650 Air Velocity Transmitter is 1 year.
