MEAS Vacuum Transmitter

Product Description

The M5200 series pressure transducers from the Microfused line of MEAS, set a new price performance standard for demanding commercial and heavy industrial applications. This series is suitable for measurement of liquid or gas pressure, even for difficult media such as contaminated water, steam, and mildly corrosive fluids. The transducer pressure cavity is machined from a solid piece of 17-4 PH stainless steel. The standard version includes a 1/4 NPT pipe thread allowing a leak-proof, all metal sealed system. There are no O-rings, welds or organics exposed to the pressure media. The durability is excellent. The M5100 exceeds the latest heavy industrial CE requirements including surge protection, and is over voltage protected to 16Vdc in both positive and reverse polarity. This product is geared to the OEM customer who uses medium to high volumes. The standard version is suitable for many applications, but the dedicated design team at our Transducer Engineering Center stands ready to provide a semi-custom design where the volume and application warrants.Features: Heavy industrial-High EMI Rated Heavy industrial CE Approval Reverse Polarity Protection Extended temperature range Compact Outline -40 to 125degree C operating Applications: Advance HAVC Controllers, Refrigeration Systems Automotive Test stands,Gas compressors,Industrial process control Pumps and compressors, Hydraulic/Pneumatic systems Agriculture equipment,Energy and water management industries Engine and vehicle, general industry,medical Pressure instrumentation Pressure instrumentation Specification Range upto1000 Bar Modle M5200 Operating Temperature -40 Degree C to +125 Degree C Total Error Band 1% EMI Protection 100 V/m Storage Temperature -45 Degree C to +125 Degree C Rated Burst Pressure 5X Rated Pressure Overload 2X Weight 82.2 gm
