Product Description
APPLICATION Used for RTD TC Ohm mV SPECIFICATIONS Power supply 1032VDC Output 420mA DC Stability 001CRTD 01CE J K N T 02CB R S 01CRTD 05CE J K N T 10CB R S Operating temperature 40C 85C Dimension C248diameter 44mmMounting hole D33 mm D3051WDdiameter 62 mmMounting hole D55 mm Specification Brand CARE Input RTD Pt100 2W / 3W / 4 W Output 4 - 20 mA, two wire Accuracy +-0.1% Storage Temperature -40 Degree C to 120 Degree C Operating Temperature -40 Degree C to 85 Degree C Loop Supply 24V DC nominal (12 to 36)V DC Loop Resistance 1600ohm @ 24V DC Protection IP-68 Update Rate 0.5 Sec. Minimum Span 10 Degree C / 18 Degree F
FAQs of Temperature Transmitter:
Q: What type of temperature transmitter is this?
A: This is an electronic temperature transmitter.
Q: What is the temperature range supported by this transmitter?
A: The temperature range is -40 to 85 Celsius (C).
Q: What are the primary applications of this temperature transmitter?
A: It is designed for industrial applications.
Q: What colors is the temperature transmitter available in?
A: The transmitter is available in gray and green colors.
Q: Can this temperature transmitter be used in a laboratory setting?
A: Yes, this transmitter is suitable for laboratory usage.
