Magnehelic Gauge Sensor

Product Description

Specifications ServiceAir and noncombustible compatible gases Natural Gas option available Note May be used with hydrogen Order a BunaN diaphragm Pressures must be less than 35 psi Wetted Materials Consult factory Housing Die cast aluminum case and bezel with acrylic cover Exterior finish is coated gray to withstand 168 hour salt spray corrosion test Accuracy 2 of FS 3 on 0 100PA 125PA 10MM and 4 on 00 60PA 6MM ranges throughout range at 70F 211C Pressure Limits 20 in Hg to 15 psig 0677 bar to 1034 bar MP option 35 psig 241 bar HP option 80 psig 552 bar Over pressure Relief plug opens at approximately 25 psig 172 bar standard gages only See Over pressure Protection note on Catalog page Temperature Limits 20 to 140F 667 to 60C 20F 28C with low temperature option Size 4 1016 mm diameter dial face Mounting Orientation Diaphragm in vertical position Consult factory for other position orientations Process Connections 18 female NPT duplicate high and low pressure taps one pair side and one pair back Weight 1 lb 2 oz 510 g MP HP 2 lb 2 oz 963 g Standard Accessories Two 18 NPT plugs for duplicate pressure taps two 18 pipe thread to rubber tubing adapters and three flush mounting adapterswith screws Mounting and snap ring retainer substituted for three adapters in MP HP gage accessories Agency Approval Meets the technical requirements of EU Directive 201165EU RoHS II Note SP models not RoHS approved
